Summary

For a few months I’ve had a basic Azure Linux box with SSH open to the world to collect the usernames brute forced and the IP address of the bot trying.

This worked OK for a while but I was only taking the username and nothing else, plus it was slightly risky if the attacker ever guessed a username or password.

What I really wanted to see was the Username and Password that was being used. From this I could build a list of compromised passwords and build out some Threat Intel of threat actors and the tools they are using. After googling around it became clear I needed some form of Honeypot that would collect the Logons and also let the attacker in. This way I can see what commands are run post breach.

After downloading and playing with a few, I stumbled across Cowrie. This ticked all the boxes needed for a simple SSH sandbox

  • Simple and flexible install
  • Robust log export
  • Low overhead
  • Logs Usernames, Passwords and Commands

Setup Cowrie

You can install Cowrie as a standalone service or run it inside a docker.

The below instructions are to install and run Cowrie without Docker. I plan on moving my current setup to Docker soon and will update with the changes needed to run inside docker later.

  1. Install the System Dependency

     sudo apt-get install git python-virtualenv libssl-dev libffi-dev build-essential libpython3-dev python3-minimal authbind virtualenv

  2. Create Cowrie User

     sudo adduser --disabled-password cowrie

  3. Clone Repo

     git clone https://github.com/cowrie/cowrie
 cd cowrie

  4. Setup Python Virtual Environment

     virtualenv --python=python3 cowrie-env
 source cowrie-env/bin/activate

  5. Setup Authbind for port 22

     sudo apt-get install authbind
 sudo touch /etc/authbind/byport/22
 sudo chown cowrie:cowrie /etc/authbind/byport/22
 sudo chmod 770 /etc/authbind/byport/22

  6. Start Cowrie

     bin/cowrie start

Sentinel Logs

Now you have Cowrie setup the ingestion of the logs into Sentinel is straightforward. To take the logs from the VM you will need to have the OMS agent setup on your Sentinel Instance.

This can be done direct from the Workspace Sentinel is attached to or by using the following commands

wget https://raw.githubusercontent.com/Microsoft/OMS-Agent-for-Linux/master/installer/scripts/onboard_agent.sh && sh onboard_agent.sh -w <YOUR WORKSPACE ID> -s <YOUR WORKSPACE PRIMARY KEY>

Once installed and the VM is sending Heartbeats you need to setup the Custom Log collector.

Open the Log Workspace and navigate to:

Settings > Custom Logs > Add Custom Log

When prompted, upload the cowrie.json file, this can be found in: Cowrie/var/log/cowrie/cowrie.json

It takes about 15min for logs to start showing in sentinel

Now the logs are in they need to be parsed, inside the Cowrie Github you will find a Function Parser that takes the RAW logs and transforms them into something useful

Cowrie Parser

Hunting

Now we have the logs in Sentinel we can start to extract interesting info:

  • What Usernames are used the most?

  • What passwords are used?

  • Where are the Attackers located?

Show Usernames and Password

Take the Cowrie logs and search for Usernames and Passwords

Cowrie
| where EventID contains "success"
| project TimeGenerated, SourceIp, Username, Password

Show Commands

Take the Cowrie logs and search for commands

Cowrie
| where EventID contains "command"
| project TimeGenerated, Input, SourceIp

Geolocate IP

My biggest pet peeve with Sentinel is GeoLocation isn’t possible by default when searching logs!

With a little hack its possible to import a CSV with locations and then transform all the IP addresses in the Cowrie table with the expropriate location

let IP_List = externaldata(network:string, continent_code:string ,continent_name:string, country_iso_code:string, country_name:string)["https://raw.githubusercontent.com/datasets/geoip2-ipv4/master/data/geoip2-ipv4.csv"] with (format="csv",ignoreFirstRecord=true);
Cowrie
| distinct tostring(SourceIp)
| evaluate ipv4_lookup(IP_List, tostring(SourceIp), network)
| summarize count() by country_name
